7 inch IPS lcd module for GPS navigation (HC070IK25035-B78V.C)

Handheld terminals,testing machine,electric bicycle,office printer

Specification parameters

Brand Hetech
P/N HC070IK25035-B78V.C
Size 7"(IPS)
Display mode IPS,Transmissive,normally black
Resolution 800X480
Aspect ratio 16:9
Outline Dimension(mm) 164.9(W) x100(H) x5.7(D)
Active Area(mm) 154.08 (W) × 85.92(H)
Brightness(cd/m²) 250cd/㎡
Viewing Angle(L/R/T/B) 80/80/80/80
Interface 50pin RGB,Parallel 24bit
Constrast ratio 500:1
Operation Temp -20℃~70℃
Storage Temp. -30℃~80℃
Backlight White LED
Application handheld terminals,testing machine,electric bicycle,office printer
