10.4 inch 1024x768 LCD display (HC104IM38059-B24)

Specification parameters

Brand Hetech
P/N HC104IM38059-B24
Size 10.4" (IPS)
Display mode IPS,Transmissive,normally white
Resolution 1024x768
Outline Dimension(mm) 228.4(H)x175.4(V)x5.9(D)
Active Area(mm) 210.43(H) x 157.82(V)
Brightness(cd/m²） 380cd/㎡
Viewing Angle(L/R/T/B) 80/80/80/80
Interface 30pin LVDS
Constrast ratio 1000:1
Operation Temp -20℃~70℃
Storage Temp. -30℃~80℃
Backlight White LED
Application automobile,car diagnostic instrument,electric motorcycle,patient monitor，Medical infusion pump, refrigerator, washing machine, air conditioner display, handheld device, car display
