10.4 inch 1024x768 LCD display for patient monitor (HC104IM65065-B24V01)

Specification parameters

Brand Hetech
P/N HC104IM65065-B24V01
Size 10.4" (IPS)
Display mode IPS,Transmissive,normally black
Resolution 1024x768
Outline Dimension(mm) 238.6 (H) x175. 8(V) x 6.5 (D)
Active Area(mm) 210.432 (H) x 157.824 (V)
Brightness(cd/m²） 650cd/㎡
Viewing Angle(L/R/T/B) 80/80/80/80
Interface 30pin LVDS
Constrast ratio 800:1
Touch panel

Capacitive touch panel:

I2C interface

CTP IC:GT911

USB

Resistive touch panel:

4 wire,5 wire

Customization:

Glass material:Glass,PC,PMMA

Treatment:AG,AR,AF

Thickness:1.0mm,1.1mm,3mm,4mm

IC:ILITECK,Goodix,EETI

Interface:I2C,USB

Bonding:Air bonding,Optical bonding available.

Operation Temp -20℃~70℃
Storage Temp. -10℃~60℃
Backlight White LED
Application automobile,car diagnostic instrument,electric motorcycle,patient monitor，Medical infusion pump, refrigerator, washing machine, air conditioner display, handheld device, car display
