128x128 resolution 1.44 inch TFT LCD panel with 12 pins(HC014TX25020-G20)

Specification parameters

P/N HC014TX25020-G20
Size 1.44"(TN)
Display type TN
Resolution 128*128
Aspect ratio 1:1
Contrast ratio 600:1
Outline Dimension(mm) 27.9(W)*32.64(H)*1.96(D)mm
Active Area(mm) 25.50(W)*26.50(H)mm
Brightness(cd/m²） 250cd/m2
Viewing Angle(L/R/T/B) 60/60/60/60
Interface 12 PIN SPI
Operation Temp -20~70℃
Storge Temp -30~80℃
Application Smart watch, USB tester, Laser Angle Ruler Protractor, Letter box, Temperature Humidity Analyzer Digital Meter
