2.4" color TFT LCD module 240*320 Resolution with SPI interface(HC024IC40025-F03V.C)

Specification parameters

P/N HC024IC40025-F03V.C
Size 2,4"(IPS)
Display type IPS
Resolution 240*320
Aspect ratio 3:4
Contrast ratio 800:1
Outline Dimension(mm) 42.92(W)*60.26(H)*3.7(D)mm
Active Area(mm) 36.72(W)*48.96(H)mm
Brightness(cd/m²） 400cd/m2
Viewing Angle(L/R/T/B) 80/80/80/80
Interface 45 PIN SPI
Operation Temp -20~70℃
Storge Temp -30~80℃
Application Handheld Dual Channel Digital Oscilloscope, Digital Metal Ultrasonic Thickness Gauge Meter
