1.2 inch 240x240 resolution TFT LCD display with SPI interface(HC012IX35016-F99)

Specification parameters

HC012IX35016-F99, a standout 1.2-inch LCD display module that marries advanced technology with exceptional performance. This module is equipped with an IPS display mode, ensuring accurate color representation and wide viewing angles for an unparalleled viewing experience. Encased within a compact frame of 32.56mm*34.31mm*1.57mm, this module provides a rich active viewing area of φ30.24mm. Experience striking detail on the 240*240 pixel resolution display that can exhibit up to 262K colors, creating a vibrant and immersive user experience. The HC012IX35016-F99 is optimized for efficient data transmission with its 16PIN SPI interface. With a luminous brightness level of 350 nits, this display remains clear and radiant under a wide array of lighting conditions. The HC012IX35016-F99 is ideal for embedded systems and handheld devices. This display module exemplifies the potent combination of practical design and innovation, making it the superior choice for excellent visual interaction.

P/N HC012IX35016-F99
Size 1.2"(IPS)
Display type IPS
Resolution 240*240
Aspect ratio 1:1
Contrast ratio 800:1
Outline Dimension(mm) 32.56(W)*34.31(H)*1.57(D)mm
Active Area(mm) φ30.24mm
Brightness(cd/m²） 350cd/m2
Viewing Angle(L/R/T/B) 80/80/80/80
Interface 16 PIN SPI
Operation Temp -20~70℃
Storge Temp -30~80℃
Application Smart gadgets, Control knob,Humanoid robot
